Add to Cart
✅ 8CH 1080P@15fps Sync Recording
✅ 5-in-1 Integration (DVR/Splitter/PTZ/Alarm/Network)
✅ H.264 Encoding (50% Storage Saving)
✅ Multi-Protocol Support: EX-SDI 2.0/TVI/AHD/CVI/IP
Engineered as the nerve center for critical surveillance, the LNE-704 revolutionizes security management by integrating five core functions into a single 1U chassis.
Leveraging EX-SDI 2.0 technology, it delivers zero-latency 1920×1080 transmission while H.264 Main Profile encoding reduces storage needs by 50%.
Dual SATA bays support 8TB capacity for 90-day continuous operation in high-risk facilities.
| Parameter | Specification |
|---|---|
| Model | LNE-704 |
| Recording Capacity | 1920×1080@15fps × 8 channels |
| Codec | H.264 Main Profile |
| Playback Speed | 1x to 128x Smart Scaling |
| Video Output | HDMI (2560×1440) + VGA |
| PTZ Control | RS-485 (Pelco-D/P Compatible) |
| Alarm I/O | 1 In / 2 Out |
| HDD Support | Dual SATA (4TB × 2 Max) |
| Protocols | EX-SDI 2.0, TVI, AHD, CVI, 960H, IP |
Bank Vaults: 8CH sync recording eliminates blind zones
Traffic Checkpoints: 128x playback accelerates license plate retrieval
Assembly Lines: Motion detection triggers incident logging
Real-Time Processing
120fps Total Bandwidth: Ensures fluid multi-camera monitoring
EX-SDI 2.0: 100m signal transmission without degradation
| Feature | LNE-704 | Standard DVRs |
|---|---|---|
| Throughput | 120fps | ≤80fps |
| Playback | 128x Speed | 64x Max |
| Input Flexibility | 6 Hybrid Protocols | 3-4 Protocols |
| Output Quality | 2K HDMI | 1080p |
